Plastic Extrusion Welding Gun PFE610B

• Top powerful handle extruder

• This type of extrusion welding gun uses a 1300w Metabo electric drill imported from Germany as the extrusion motor, with high power, low resistance and strong protection. Using 3400w hot air blower and 800w welding rod heating coil double heating system, the heating temperature of base material and welding rod can be independently controlled. Especially for the welding of thick plastic plates, it has great advantages, high welding efficiency and good welding seam quality. Equipped with digital welding electrode heating temperature control display, anti-scalding design welding nozzle, convenient operation, stable performance, large extrusion capacity, and continuous welding. This type of extrusion welding gun is mainly used for welding of thermoplastic materials such as PE, PP, etc., such as plates, films, pipes, water tanks, and plastic parts.

• The intelligent control system adopts double protection, drive motor cold start protection, automatic heating temperature compensation, improve the reliability of the extrusion welding gun, try to avoid malfunctions caused by misoperation, and extend the service life of the machine.

• Provide neutral packaging and small batch customization services.

• Provide small batch customization services for various welding boots.

• The LCD display of the control box is more intuitive and convenient.

• Third-party CE certification test.

Categories: ,


Extrusion welding machine with maximum power, fast heating and high efficiency.

Dual heating system

The electrode feeding heating system and hot air heating system ensure the best welding quality.

Digital display controller

Microcomputer chip control, simple and intuitive operation, strong protection function.

Motor cold start protection

The extrusion motor will automatically stop if it does not reach the set melting temperature, avoiding losses caused by operating errors.

High-quality drive motor

The extrusion motor uses a German 1300w Metabo drill bit.


Model LST610B
Rated Voltage 230V
Frequency 50/60HZ
Extruding Motor Power 1300W
Hot Air Power 3400W
Welding Rod Heating Power 800W
Air Temperature 20-620℃
Extruding Temperature 50-380℃
Extruding Volume 2.0-3.0kg/h
Welding Rod Diameter φ3.0-5.0mm
Driving Motor METABO
Body weight 7.2kg
Certification CE
Warranty 1 year


Repair geomembrane

LST610B type
